Disk Refiners

45-1B Disk Refiner Andritz 3000 HP Completely Rebuilt. To Include: Disassembly inspection and rebuild of the Rotor Sleeve Fit Stator Disc Face Base with new custom oil hoses FE Pedestal TE Pedestal Swing Door / Plate Holder Plate Adjusting Assembly Rotary Air Seal Door Throat Liner Bearings. 45-1B Refiner General Overhaul Operations: Steam clean the interior and exterior of oil tank of base. Sandblast and coat with rust preventive. Plane both top and bottom surfaces to within .002 T.I.R. if necessary. Trim side register .030 to allow for alignment of stator and pedestals. Dynamically balance Rotor and Disc assembly to ISO standard G1.0. Qualify all bearings for optimum mounted internal clearance. Assemble bearings housings and seal assemblies on the shaft and set thrust bearing end play. Assemble the refiner complete installing new oil piping hoses and drains. Connect oil system and fill tank with oil for test running. Test run refiner for 1 hour to establish assembled refiner vibration and bearing sound levels. Paint and detail all parts. Prepare refiner for delivery to customer.

45-1B Sprout Waldron Disk Refiner Completely Rebuilt Immediately Available. Operates at 2500 HP and 4000 Volt.

Twin 50 Disk Refiner Sprout Waldron / Andritz. This machine has been professionally dismantled and rebuilt. The refiner is immediately available to put into service. Includes Feeder Assembly and Steaming Tube.

Beloit Jones 34 Inch DD Model 3500 Disc Refiner. Recently Upgraded From A 3000 Series This Refiner Is Electro Mechanically Actuated And In Good Condition. Upgraded In 2005.

Beloit Series 4000 DD 34 Inch Disc Refiner. Model Number 4334S.

Beloit Jones series 3000 20" disc refiner Mono flow.

Sprout Waldron R20EM Refiner: Model No. R20EM; L-64 W-48 H-48

Beloit Model No. DD3000 20" Refiner Housing w/ Door; L-84 W-48 H-48

Andritz Model TF 34 Double Disc Refiner 34" Rotor Stainless steel Casing Less Door

Metso Optifiner Conica refiner; Size DF-1; Mfg 2006; Model No. Optifiner DF-1; L-60 W-36 H-45; 2774 Lbs

Bauer Model No 480-1 Refiner Control End Rotating Assembly; Size 48" Disc; Unused Storeroom Spare

Andritz 34" Twin Flo III Refiner Rebuilt By Gl&V In 2007 Converted To Spline Type Rotor Stainless Steel Inlet With 3 Hp Ac Set-Up Motor 230 Volt 1726 Rpm We182tc Frame Single Inlet

Andritz R20 EMA II 20" Disc Refiner

Sprout Waldron R20 EM Disc Refiner With Sev-Usocome A/C Motor
